Specification
| Supply voltage Adaptor | 100 to 240 VAC, 50/60 Hz |
| Current Consumption voltage Adaptor | 1.9 A (100 VAC) to 1 A 240 (VAC) |
| DC voltage Control Unit | 24 V, 6.0 A |
| Maximum number of Discussion Devices per Extension Unit | 40 Discussion Devices per trunk/tap-off 85 Discussion Devices in total 24 V, Max 5.2 A (short-circuited protected) |
| Dimensions including feet(H x W x D) | 45 x 440 x 200 mm(1.8 x 17.3 x 7.9 in) 19” wide, 1 RU high |
| Height of feet | 5.5 mm (0.2 in) |
| Mounting | Tabletop or 19” rack |
| Weight | Approx. 4.12 kg (9.1 lb) |
| Material (top and base) | Painted metal |
| Color (top and base) | Traffic black (RAL 9017) matt-gloss |
| Rim front panel | Pearl light grey (RAL 9022) matt-gloss |
| Operating temperature | 5 ºC to +45 ºC (+41 ºF to +113 ºF) |
