CCS-DS a new european design delegateconference unit, enabling participants to speak, register a request to speak, and listen to the speaker. The microphone stem is extremely flexible, so the microphone can be used by delegates sitting on either side of the unit, thus allowing one unit to serve two delegates.
The unit also accommodates two separate headphones, so the speaker can be heard clearly even in situations with excessive background noise. This aesthetically-pleasing unit has a built-in loudspeaker which is muted when the microphone is on to prevent acoustic feedback.
Controls and indicators
- Microphone with red illuminated indicator ring, lights when the microphone is ON.
- Bi-color LED indicator above the microphone push button. Red for microphone on, white for Possible-To-Speak indicator (Delegate Unit only)
- Two 3.5 mm stereo headphone sockets, one at each side, for headphone or recorder connection.
- Built-in loudspeaker, automatically muted when the microphone is ON.
- 7-pole circular female socket for loopthrough connection to the next unit
- 2m flying lead connection cable with sturdy moulded 7-pole circular male connector for connection to the previous unit or CU.
- Rotary volume control for headphones only
- Microphone ON/OFF push-button.
Interconnection
- 2 m (78.7 in) cable terminated in a moulded 7-pole circular connector for connection to delegate unit or CPSU
- 7-pole circular female socket for loop-through connection to delegate units
- Two 3.5 mm (0.14 in) stereo headphone sockets
